Operation 40075165 Markoprint integra PP108
Page 63 of 104 GB
Loading print image
Print Images can load to the Markoprint integra PP108 print system as follows:
USB-Stick
Software iDesign with existing network connection via RJ45 or
By serial interface EIA 232
Load print images incl. fonts, logos and parameter with a USB-stick automatically.
The files can load to a USB-stick by iDesign.
After the connection of a USB stick an automatic run of commands will be made to query
the system status.
At the same time a directory „Markoprint“ and a subdirectory with the name of the serial
number of the system, i.e. „L12003-x1“ will be created in the main directory of the USB
stick. There will be saved all system specific data.
The stick must be connected once on the system to post this information, so that the
iDesign software can work with the system after that.
The transfer of the data and commands happen by the Markoprint integra PP108 directly
after the connection of the stick. After this the „Status.ast“ file is created.
Process:
After the connection and identification of the stick, the data will be read from the stick
and the Status LED flashes quickly meanwhile (4x/second)
Thereafter, data written on the stick and the Status LED flashes slowly meanwhile
(2x/second)
If the LED lights constant, the stick can removed after 2 seconds.
