Boot-LED messages
During booting of the system progress can be determined by means of the LED.
If the system stops during booting the cause can be determined by means of the LED.
FC means flashing. An error can be determined on the basis of the number of flashes.
Status-LED
Sensor-LED
Description
ye
ye
Boot BF-Intern
rd
—
Write 64MB memory
—
rd
Read/invert 64MB memory
ye
—
Read/test 64MB memory
—
ye
Test ok / Load BootMain from SPI
ye
rd
Programming and start of BootMain
—
—
BootMain initialization
rd
rd
Fatal error
rd
FC:
rd
Boot-error 4x = SPI; 5x = GA; 6x = Displ; 7x = SD-Card; 8x = USB;
9x = RTC; 10x = Task
rd
FC:
gn
Init-error 1x = Dev; 2x = FS; 3x= UsrCl
ge
gn
Read SD-Card
ye
rd /
gn
Wait for Stick
ye
rd / —
No boot data
ye
ye /
gn
Booting of stick?
ye
ye /
rd
Copying of stick?
ye
gn / —
Copy Ok
gn
—
Main program loaded and started
