Appendix 40075165 Markoprint integra PP108
Page 93 of 104 GB
Plug connections
Ethernet
Connection
Network input RJ45 on the back side of the system.
PIN
Description
1
Transmit+
2
Transmit-
3
Receive+
6
Receive-
USB A
The USB sockets are standard sockets, as used in commercial PCs and USB devices.
Insert the USB-stick without force effect normal to the top side of the system in the USB
socket.
PIN
Name
Color
Description
1
VCC
Red
+5 V
2
D-
White
Data -
3
D+
Green
Data +
4
GND
Black
Mass
