Weber Markoprint integra PP108 - Sensors; Encoder

Appendix 40075165 Markoprint integra PP108
Page 97 of 104 GB
Sensors
Sensor input:
Standard: NPN (switching to GND)
Voltage: 12V (10-30V)
Threshold level: 7V
Is the input is switched to PNP a resistance of ca. 2kOhm must connected between the
input (Pin10) and ground (Pin1).
Encoder
Encoder input:
Standard: Push-pull or NPN (switching to GND)
Voltage: 12V (10-30V)
Threshold level: 7V
Frequency: Max. 150 kHz
