Weber Markoprint integra PP108 User Manual

Appendix 40075165 Markoprint integra PP108
Page 94 of 104 GB
Option
Option socket: 15 pol Sub-D connector
PIN
Description
Value
Unit
1
GND
0
V
2
Output 1 (Alarm)
Open Collector,
max 24V / 100mA
3
Input 1
Input Standard: NPN
4
Input 2
Input Standard: NPN
5
Output 3 (Ok)
Open Collector,
max 24V / 100mA
6
Output 4 (Reserve)
Open Collector,
max 24V / 100mA
7
EIA 232
TXD
8
GND
0
V
9
Output 2 (Warning)
Open Collector,
max 24V / 100mA
10
Start pulse
Input Standard: NPN
11
Shaft encoder
Input Standard: NPN
12
Not used
13
Not used
14
EIA 232
RXD
15
Power
+12
V
