SSW-06 - QUICK PARAMETER REFERENCE
Parameter Description Adjustable Range Factory Unit User´s Pag e
Setting Setting
3=External By-pass
4=FWD/REV-K1
5=DC-Brake
6= No Fault
7=Fault
8=Fieldbus
9=Serial
  10=SoftPLC
11=No Alarm
12=Alarm
13=Breaker Shunt Trip
P278
(1)
 RL2RelayFunction 0=NotUsed 2=FullVoltage - 114
1=Running
2=Full Voltage
3=External By-pass
4=FWD/REV-K2
5=DC-Brake
6= No Fault
7=Fault
8=Fieldbus
9=Serial
  10=SoftPLC
11=No Alarm
12=Alarm
13=Breaker Shunt Trip
P279
(1)
 RL3RelayFunction 0=NotUsed 6=NoFault - 114
1=Running
2=Full Voltage
3=External By-pass
4= Not Used
5=DC-Brake
6=No Fault
7=Fault
8=Fieldbus
9=Serial
  10=SoftPLC
11=No Alarm
12=Alarm
13=Breaker Shunt Trip
Soft-Starter Data
P295
(1)(2)
SSW Nominal Current 0=10 11=312 According to A 115
1=16 12=365 Soft-Starter
2=23 13=412 Nominal Current
3=30 14=480
4=45 15=604
5=60 16=670
6=85 17=820
7=130 18=950
8=170 19=1100
9=205 20=1400
10=255 21=1000
22=1300
