WEG SSW-06 User Manual

Summary
Quick Parameter Reference,
Fault and Status Messages
I Parameters ...........................................................................................09 II
Fault or Alarm Messages ........................................................................ 21
III Other Messages .................................................................................21
CHAPTER 1
Safety Notices
1.1 Safety Notices in the Manual ............................................................ 22
1.2 Safety Notices on the Product ..........................................................22
1.3 Preliminary Recommendations.........................................................23
CHAPTER 2
General Information
2.1 About this Manual .............................................................................24
2.2 Software Version ..............................................................................24
2.3 About the Soft-Starter SSW-06 .........................................................24
2.4Soft-StarterSSW-06Identication ....................................................28
2.5 Receiving and Storage .....................................................................30
CHAPTER 3
Installation and Connection
3.1 Mechanical Installation .....................................................................31
3.1.1 Environment Conditions .............................................................31
3.1.2 Dimensions of the Soft-Starter SSW-06 .....................................31
3.1.3 Positioning / Fixing .....................................................................32
3.1.3.1 Mounting inside a Panel ....................................................33
3.1.3.2 Mounting on a Surface ......................................................36
3.2 Electrical Installation ......................................................................... 37
3.2.1 Power Terminals .........................................................................38
 3.2.2LocationofthePower/Grounding,ControlConnectionsand
Fan Voltage Selection ................................................................. 43
3.2.3 Recommended Power/Grounding Cables ..................................44
3.2.4 Connection of the Power Supply to the Soft-Starter ...................47
  3.2.4.1ShortCircuitCapacity,fuses,circuitbreaker-UL ............48
3.2.4.2 Input Circuit Breakers and Fuses - IEC .............................50
3.2.5 Connection of the SSW-06 Soft-Starter to the motor .................. 52
3.2.5.1 Standard Three-Wire Connection (P150=0=Inactive) .......52
3.2.5.2 Inside Delta Motor Connection (P150=1=Active) ..............53
3.2.6 Grounding Connections ..............................................................54
3.2.7 Fan Connections ........................................................................55
3.2.8 Signal and Control Connections ................................................. 56
3.2.9 RS-232, X2 Serial Communication Connection .........................59
3.2.10 XC8 Serial Communication Board Connection ........................59
3.2.11 XC6 Fieldbus Communication Board Connection ....................59

WEG SSW-06 Specifications

General

Brand	WEG
Model	SSW-06
Category	Controller
Language	English
