CHAPTER 3 - INSTALLATION AND CONNECTION
33
Figure 3.2 - Free spaces for cooling
C
A
Y
BB
Air Flow Outlet
Air Flow Inlet
When the Soft-Starters SSW-06 are installed in panels or closed
metallic boxes, adequate cooling is required to ensure that the tem-
perature around the inverter will not exceed the maximum allowed
temperature. See dissipated power in the table 3.4.
3.1.3.1 Mounting inside a Panel
Table 3.2 - Recommended free spaces
A
mm (in)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
220-575 V
SSW06.0010
SSW06.0016
SSW06.0023
SSW06.0030
SSW06.0045
SSW06.0060
SSW06.0085
SSW06.0130
SSW06.0170
SSW06.0205
-
SSW06.0255
SSW06.0312
SSW06.0365
SSW06.0412
SSW06.0480
SSW06.0604
SSW06.0670
SSW06.0820
SSW06.0950
SSW06.1100
SSW06.1400
B
mm (in)
30 (1.18)
30 (1.18)
30 (1.18)
30 (1.18)
30 (1.18)
30 (1.18)
30 (1.18)
100 (3.93)
C
mm (in)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
150 (5.90)
Y
mm (in)
50 (1.96)
50 (1.96)
50 (1.96)
50 (1.96)
50 (1.96)
50 (1.96)
50 (1.96)
50 (1.96)
575-690 V
-
-
-
-
SSW06.0045
SSW06.0060
SSW06.0085
-
SSW06.0130
SSW06.0170
SSW06.0205
SSW06.0255
SSW06.0312
SSW06.0365
SSW06.0412
SSW06.0480
SSW06.0604
SSW06.0670
SSW06.0820
SSW06.0950
SSW06.1100
SSW06.1400
Model
