WEG SSW-06 User Manual

9
SSW-06 - QUICK PARAMETER REFERENCE
QUICKPARAMETERREFERENCE,FAULTANDSTATUSMESSAGES
Software: V1.8X
Application:
Model:
Serial Number:
Person Responsible:
Date: / / .
I. Parameters
Par am eter Description Adjustable Range Factory Unit User´s Page
Setting Setting
P000 Parameter Access 0 to 999 0 - 84
READ ONLY PARAMETERS P001 to P099
P001 Soft-Starter Current 0 to 999.9 - % 85
(%In of the Soft-Starter)
P002 Motor Current 0 to 999.9 - % 85
(%In of the Motor)
P003 Motor Current 0 to 9999.9 - A 85
P004 LineVoltage 0to999 - V 85
P005 LineFrequency 0to99.9 - Hz 85
P006 Soft-Starter Status 0=Ready - - 86
1=Initial Test
2=Error
3=Ramp Up
4=Full Voltage
5=By-pass
6=Reserved
7=Ramp Down
8=Braking
9=FWD/REV
10=JOG
11=Delay P630
12=General Disable
P007 Output Voltage 0 to 999 - V 86
P008 Power Factor 0 to 1.00 - - 86
P009 Motor Torque (% Tn of the Motor) 0 to 999.9 - % 86
P010 Output Power 0 to 6553.5 - kW 87
P011 Apparent Output Power 0 to 6553.5 - kVA 87
P012 Dl1 to DI6 Status 0=Inactive - - 87
1=Active
P013 RL1,RL2andRL3Status 0=Inactive - - 88
1=Active
P014 LastFault 0to99 - - 88
P015 Second Previous Fault 0 to 99 - - 88
P016 Third Previous Fault 0 to 99 - - 88
P017 Fourth Previous Fault 0 to 99 - - 88
P018 Fifth Fault 0 to 99 - - 88
P019 Sixth Fault 0 to 99 - - 88
P020 Current Fault 0 to 99 - - 89
P021 Current Alarm 0 to 99 - - 89
P023 Software Version X.XX - - 89
P027 AO1 Output Value 0 to 10.000 - V 89
P028 AO2 Output Value 0 to 20.000 or 4.000 to 20.000 - mA 89
