87
DETAILEDPARAMETERDESCRIPTION
This Chapter describes in detail all Soft-Starter SSW-06 parameters. In order
to simplify the explanation, the parameters have been grouped by characte-
ristics and functions:
Symbolsanddenitionsusedinthetextbelow:
(1) Indicates that the parameter can only be changed when the Soft-Starter
SSW-06 is disabled (motor stopped).
(2) Parameters not changed when programmed to Factory Default (P204=5).
6.1 ACCESSANDREADONLYPARAMETERS-P000toP099
 This parameter opens the access to change the parameter values.
When values are set according to Factory Default [P200 = 1 (Pas-
sword is active)] set P000 = 5 to change parameter values, and the
Password value is equal to 5.
 By programming P000 with the password that releases access to
change parameter contents, plus 1 (Password + 1), you will obtain
accessonlytotheparameterswithcontentsdi󰀨erentfromthefactory
setting.
 To change the password to any other value (password 1), proceed
as follows:
(1) Set P000=5 (current password) and P200= 0 (password inactive).
(2) Press the key .
(3) Change P200 to 1 (password active).
(4) Press the key again: display shows P000.
(5) Press the key again: display shows 5 (last password).
(6) Use the keys and to change to the desired password
value (password 1).
(7) Press the key : display shows P000. From this moment on,
the new password becomes active. Thus, to change parameter
content P000 must be set to the new password. (Password 1).
P000 0 to 999
Parameter Access [0]
Password Value -
Setting
Range
[Factory Setting]
Parameter Unit Description / Notes
Read Only Parameters Variables that can only be viewed on the display but
not changed by the user.
Regulation Parameters Programmable values used by the Soft-Starter
SSW-06 functions.
 CongurationParameters TheseParametersdenetheSoft-Starter 
SSW-06 characteristics, the functions to be executed,
as well as the input/output functions of the control board.
Motor Parameters Motor data that are indicated on the motor nameplate.
Special Function Parameters Here are the parameters related to special functions.
Protection Parameters Here are the parameters related to actuation levels
and actuation time of the motor protection.
CHAPTER 6
