WEG SSW-06 User Manual

CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
88
 Indicates Soft-Starter SSW-06 output current as percentage of the
nominal current of the Soft-Starter (%In of the SSW-06) .
 Precision of ± 2% for the full scale. (The full scale is 5 x ln of the
SSW-06).
NOTE!
When the motor connection is inside delta (P150=1), the indi-
cation of the current value will already be multiplied by 1.73.
P001 0 to 999.9
Soft- Starter SSW-06 [ - ]
Current 0.1%
Range
[Factory Setting]
Parameter Unit Description / Notes
 Indicates Soft-Starter SSW-06 Output Current as percentage of the
nominal motor current (%In of the motor).
 Precision of ± 2% for the full scale. (The full scale is 5 x ln of the
SSW-06).
NOTE!
When the motor connection is inside delta (P150=1), the
indication of the current value will already be multiplied by 1.73.
P002 0 to 999.9
Motor Current [ - ]
0.1%
Indicates the Soft-Starter SSW-06 output current in Amperes (A).
 Precision of ± 2% for the full scale. (The full scale is 5 x ln of the
SSW-06).
NOTE!
When the motor connection is inside delta (P150=1), the indication
of the current value will already be multiplied by 1.73.
P003 0 to 9999.9
Motor Current [ - ]
0.1A
 Indicates the average True rms voltage of the three input phases in
Volts (V).
 Accuracy: ± 2V.
NOTE!
The voltage will only be indicated when it reaches a value gre-
ater than 15V. Below this value, only 0 (zero) will be indicated.
P004 0 to 999
LineVoltage [-]
1V
 Indicates the line frequency in Hertz (Hz).
 Precision of ± 5% of the nominal frequency of the supply network.
NOTE!
Only indicates network frequency when there is a voltage greater
than20Vrmsinthepowersupply(R/1L1,S/3L2andT/5L3).
P005 0 to 99.9
LineFrequency [-]
0.1Hz
