WEG SSW-06 User Manual

21
SSW-06 - QUICK PARAMETER REFERENCE
II. Fault or Alarm Messages
Display Description Page
E03 Undervoltage, Phase Fault or Phase 160
Unbalancing
E04 Overtemperature at the Power Assembly 160
E05 or A05 Motor Overload 160
E06 or A06 External Fault or Alarm (DI) 160
E10 Copy Function Fault 160
E11 Ground Fault 161
E15 Motor is not Connected or SCRs in Short-circuit 161
E16 or A16 Overvoltage 161
E18 Wrong Motor Connection 161
E19 Short Circuit in the SSW Power 161
E24 Programming Error 161
E28 Timeout Error in the Telegram Reception 161
E29 InactiveFieldbuscommunicationorProbus 161
master in Stop Fault
E30 Fieldbus Board is Inactive 161
E31 Keypad Connection Fault 161
E32 or A32 Motor Overtemperature (DI) 162
E33 or A33 Motor Overtemperature Ch1 162
E34 or A34 Motor Overtemperature Ch2 162
E35 or A35 Motor Overtemperature Ch3 162
E36 or A36 Motor Overtemperature Ch4 162
E37 or A37 Motor Overtemperature Ch5 162
E39 Without Optional PT106 Card 162
E41 Self-Diagnosis Fault 162
E43 or A43 Ch1 Motor Temperature Broken Cable 162
E44 or A44 Ch2 Motor Temperature Broken Cable 162
E45 or A45 Ch3 Motor Temperature Broken Cable 162
E46 or A46 Ch4 Motor Temperature Broken Cable 162
E47 or A47 Ch5 Motor Temperature Broken Cable 162
E48 or A48 Ch1 Motor Temperature Short Circuit 163
E49 or A49 Ch2 Motor Temperature Short Circuit 163
E50 or A50 Ch3 Motor Temperature Short Circuit 163
E51 or A51 Ch4 Motor Temperature Short Circuit 163
E52 or A52 Ch5 Motor Temperature Short Circuit 163
E57 Failure in SCR R-U 163
E58 Failure in SCR S-V 163
E59 Failure in SCR T-W 163
E62 StartLimitingTime 163
E63 LockedRotor 163
E65 or A65 Undercurrent 163
E66 or A66 Overcurrent 163
E67 Inverted Phase Sequence 163
E70 Undervoltage at the Electronics 164
E71 By-pass Contact is Open 164
E72 Overcurrent before By-pass Contact 164
E74 Current Imbalance 164
E75 FrequencyofSupplyLineoutofPermittedRange 164
E76 Undercurrent before By-pass 164
E77 By-pass Contact is closed or SCRs in Short-circuit 164
E78 or A78 Undertorque 164
E79 or A79 Overtorque 164
E80 or A80 Underpower 164
E81 or A81 Overpower 165
E85 WithoutSoftPLC 165
E86 to E89 SoftPLCusererrors 165
A90 to A93 SoftPLCuseralarms 165
III. Other Messages
For more details see table 8.1 in chapter 8.
Display Description
rdy Soft-Starter is ready to be enabled
Exx Soft-Starter fault
Axx Soft-Starter with alarm
