SSW-06 - QUICK PARAMETER REFERENCE
20
Parameter Description Adjustable Range Factory Unit User´s Pag e
Setting Setting
Notes presented on Quick Parameter Reference:
(1) This parameter can only be changed with the motor stopped;
(2) This parameter does not change when factory defaults are loaded
(P204=5).
SELECTION BETWEEN FAULT OR ALARM P700 to P790
P705 Motor Thermal Protection Trip 0=Fault E05 0=Fault E05 - 137
1=Alarm A05
2=Fault and Alarm
P706 Open DIx Protection Trip 0=Fault E06 0=Fault E06 - 138
1=Alarm A06
P716 LineOvervoltageTrip 0=FaultE16 0=FaultE16 - 138
1=Alarm A16
P732 Motor Overtemperature – PTC – Trip 0=Fault E32 0=Fault E32 - 138
1=Alarm A32
P765 Motor Undercurrent Trip 0=Fault E65 0=Fault E65 - 138
1=Alarm A65
P766 Motor Overcurrent Trip 0=Fault E66 0=Fault E66 - 138
1=Alarm A66
P778 Motor Undertorque Trip 0=Fault E78 0=Fault E78 - 138
1=Alarm A78
P779 Motor Overtorque Trip 0=Fault E79 0=Fault E79 - 138
1=Alarm A79
P780 Motor Underpower Trip 0=Fault E80 0=Fault E80 - 138
1=Alarm A80
P781 Motor Overpower Trip 0=Fault E81 0=Fault E81 - 138
1=Alarm A81
SOFTPLC PARAMETERS P950 to P999
Control Parameters
P950
(2)
 EnableSoftPLC 0=No 0=No - 139
1=Yes
P951 Digital Inputs and Outputs Expansion 0=No 0=No 139
Card Enable 1=Yes
User Parameters
P952 FirstSoftPLCUserParameter 0to65535 0 - 139
P953 SecondSoftPLCUserParameter 0to65535 0 - 139
P954 ThirdSoftPLCUserParameter 0to65535 0 - 139
P955 FourthSoftPLCUserParameter 0to65535 0 - 139
P956 FifthSoftPLCUserParameter 0to65535 0 - 139
P957 SixthSoftPLCUserParameter 0to65535 0 - 139
P958 SeventhSoftPLCUserParameter 0to65535 0 - 139
P959 EighthSoftPLCUserParameter 0to65535 0 - 139
P960 NinthSoftPLCUserParameter 0to65535 0 - 139
P961 TenthSoftPLCUserParameter 0to65535 0 - 139
P962 EleventhSoftPLCUserParameter 0to65535 0 - 139
P963 TwelfthSoftPLCUserParameter 0to65535 0 - 139
P964 ThirteenthSoftPLCUserParameter 0to65535 0 - 139
P965 FourteenthSoftPLCUserParameter 0to65535 0 - 139
P966 FifteenthSoftPLCUserParameter 0to65535 0 - 139
P967 SixteenthSoftPLCUserParameter 0to65535 0 - 139
P968 SeventeenthSoftPLCUserParameter 0to65535 0 - 139
P969 EighteenthSoftPLCUserParameter 0to65535 0 - 139
