CHAPTER 10 - TECHNICAL SPECIFICATIONS
186
10.3 POWER DATA
Supply
Capacity
PowervoltageACinput(R/1L1,S/3L2,T/5L3)
Frequency
Maximum number of starts per hour
Starting Cycle
(220 to 575)Vac (-15% to +10%), or (187 to 632)Vac
(575 to 690)Vac (-15% to +10%) or (489 to 759)Vac
50 to 60Hz (± 10 %), or (45 to 66)Hz
10 (1 every 6 minutes) Models 10A to 820A.
5 (1 every 12 minutes) Models 950A to 1400A.
Standard motor connection
2 x InSSW during 60s
3 x InSSW during 30s
4.5 x (InSSW x 2/3) during 30s
Inside delta motor connection
2 x InSSW during 50s
3 x InSSW during 25s
4.5 x (InSSW x 2/3) during 25s
Maximum reverse peak voltage 1600V
III(UL508/EN61010)
Overvoltage Category
10.4ELECTRONICS/PROGRAMMINGDATA
(110 to 230)Vac (-15% to +10%), or (94 to 253)Vac
(50 to 60)Hz (± 10 %), or (45 to 66)Hz
 280mA Maximum
 Voltage Ramp;
 CurrentLimit;
 Pump Control;
 Torque Control;
 Current Control.
 5 isolated digital inputs;
 Minimum high level: 18Vdc;
 Maximum low level: 3Vdc;
 Maximum Voltage: 30Vdc;
 Input Current: 11mA @ 24Vdc;
 Programmable functions.
 1 input for motor thermistor;
 Actuation: 3k9Ω Release: 1k6Ω;
 Minimum resistance: 100Ω;
 PTCB referenced to the DGND through 249Ω resistor.
 1analogoutput,notisolated,(0to+10)V,RL≥ 10kΩ (maximum load);
 Resolution: 11bits;
 Programmable functions.
 1analogoutput,notisolated,(0to20)mA/(4to20)mA,RL=500Ω/1%@10V;
 Resolution: 11bits;
 Programmable functions.
 2 relays with NO-contacts, 240Vac, 1A, programmable functions;
 1 relay with NO/NC-contact, 240Vac, 1A, programmable functions.
Supply Control Voltage
Connector X1A (1,2)
Frequency
Consumption
Control Method
Inputs Digitals
Motor Thermistor
Input
Outputs Analogs
Relay
Thyristors (SCRs)
