CHAPTER 10 - TECHNICAL SPECIFICATIONS

187

10.4ELECTRONICS/PROGRAMMINGDATA(CONT.)

 Overcurrent;

 Undercurrent;

 Overvoltage;

 Undervoltage;

 Phase loss;

 Reversed phase sequence;

 Overtemperature of heatsink;

 Motor overload;

 External fault;

 OpenBy-passcontact(whenSoft-StarteristtedwithinternalBy-pass);

 OvercurrentbeforeBy-pass(whenSoft-StarteristtedwithinternalBy-pass);

 CPU Error;

 Keypad communication error.

 Programming error;

 8keys:Enable/Disable,Increment,Decrement,DirectionofRotation,Jog,Local/

Remote and Programming;

 LCD-Display,2linesx16columnsand7segments4digitsLEDdisplay

 Led’sforindicationofthedirectionofrotationandindicationontheModeof

Operation(LOCAL/REMOTE);

 Permits access/changing of all parameters;

 External mounting is possible, cables up to 5m (16.40ft) are available.

Safety Protections

Keypad HMI-SSW06
