CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
106
Range
[Factory Setting]
Parameter Unit Description / Notes
P202
(1)
0 to 4
Type of Control [ 0=Voltage
Ramp ]
-
P202
0
1
2
3
4
Type of Control
Voltage Ramp
CurrentLimit
Pump Control
Torque Control
Current Ramp
Table 6.20 - Types of control
Soft-StarterSSW-06hasvestartingcontroltypestobettermatch
all application requirements.
Start by Voltage Ramp
(1)
:
The start by Voltage Ramp is the most used starting method. The
Soft-Starter SSW-06 applies the voltage to the motor without voltage
or current feedback. This method is used for loads with lower initial
torque or quadratic torque.
This type of control can be used as initial operating test.
Start by Current Limit
(2)
:
The maximum current level is maintained during the start and is set
according to the application requirements.
This method is used for loads with higher initial torque or constant
torque.
This type of control is used for matching the start process to the limits
of the power supply capacity.
Start by Current Ramp
(3)
:
The maximum current level is limited during the start process, however
higher or lower current limits can be set during the beginning of the
start sequence.
6.3 CONFIGURATION PARAMETERS - P200 to P299
With the Factory Setting, the password will be P000=5.
To change the Password, see P000.
P200 0 to 1
Password [ 1 ]
-
P200
0 (Inactive)
1 (Active)
Action
This Parameter allows parameter content changing, indepen-
dent of P000
Change of Parameter content is only possible, when P000 is
equal to the password value
P201
(2)
0 to 3
LanguageSelection [Tobedened
by the user]
-
Table 6.18 - Password
P201
0
1
2
3
Description
Português
English
Español
Deutsch
Table 6.19 - Language selection
