WEG SSW-06 User Manual

SSW-06 - QUICK PARAMETER REFERENCE
10
Par am eter Description Adjustable Range Factory Unit User´s Page
Setting Setting
P030 Current of Phase R 0 to 9999.9 - A 89
P031 Current of Phase S 0 to 9999.9 - A 89
P032 Current of Phase T 0 to 9999.9 - A 89
P033 LineVoltage-R-S 0to999 - V 89
P034 LineVoltage-S-T 0to999 - V 89
P035 LineVoltage-T-R 0to999 - V 89
P042 Time Powered 0 to 65535 - h 90
P043 Time Enabled 0 to 6553,5 - h 90
P044 kWh Counter 0 to 999.9 - kWh 90
P045 MWh Counter 0 to 9999 - MWh 90
P047 Maximum Starting Current 0 to 9999.9 - A 90
P048 Average Starting Current 0 to 9999.9 - A 90
P049 Real Starting Time 0 to 999 - s 90
P050 Motor Thermal Protection Status 0 to 250 - % 91
P053 Maximum Current at Full Voltage 0 to 9999.9 - A 91
P054 MaximumLineVoltagewiththe 0to999 - V 91
Motor Running
P055 MinimumLineVoltagewiththe 0to999 - V 91
Motor Running
P056 MaximumLineFrequencywiththe 0to99 - Hz 91
Motor Running
P057 MinimumLineFrequencywiththe 0to99 - Hz 92
Motor Running
P058 Maximum Number of Starts per Hour 0 to 32 - - 92
P059 Total Number of Starts 0 to 65535 - - 92
P060 CurrentattheLastFault 0to9999.9 - A 92
P061 VoltageattheLastFault 0to999 - V 92
P062 SSWStatusattheLastFault 0to12 - - 92
P063 Current at the Second Fault 0 to 9999.9 - A 92
P064 Voltage at the Second Fault 0 to 999 - V 92
P065 SSW Status at the Second Fault 0 to 12 - - 92
P066 Current at the Third Fault 0 to 9999.9 - A 92
P067 Voltage at the Third Fault 0 to 999 - V 92
P068 SSW Status at the Third Fault 0 to 12 - - 92
P069 Current at the Fourth Fault 0 to 9999.9 - A 92
P070 Voltage at the Fourth Fault 0 to 999 - V 92
P071 SSW Status at the Fourth Fault 0 to 12 - - 92
P072 Current at the Fifth Fault 0 to 9999.9 - A 92
P073 Voltage at the Fifth Fault 0 to 999 - V 92
P074 SSW Status at the Fifth Fault 0 to 12 - - 92
P075 Current at the Sixth Fault 0 to 9999.9 - A 92
P076 Voltage at the Sixth Fault 0 to 999 - V 92
P077 SSW Status at the Sixth Fault 0 to 12 - - 92
P085 FieldbusCommunication 0=O󰀨 - - 93
Board Status 1=Board Inactive
  2=BoardActiveandO󰀪ine
3=Board Active and Online
P088 SoftPLCStatus 0=Without - - 93
  1=Loading
2=Fault
3=Stopped
4=Running
