SSW-06 - QUICK PARAMETER REFERENCE
Par am eter Description Adjustable Range Factory Unit User´s P age
Setting Setting
P089 AllowsSoftPLC 0=No - - 93
1=Yes
P091 Motor Temperature Channel 1 -20 to 260 - ºC 93
P092 Motor Temperature Channel 2 -20 to 260 - ºC 93
P093 Motor Temperature Channel 3 -20 to 260 - ºC 93
P094 Motor Temperature Channel 4 -20 to 260 - ºC 93
P095 Motor Temperature Channel 5 -20 to 260 - ºC 93
REGULATION PARAMETERS P100 to P199
Voltage Ramp
P101 Initial Voltage 25 to 90 30 % 94
(% Un of the motor)
P102 Acceleration Ramp Time 1 to 999 20 s 94
P103 Deceleration Voltage Step 100=Inactive 100=Inactive % 95
(% Un of the motor) 99 to 60
P104 Deceleration Ramp Time 0=Inactive 0=Inactive s 95
1 to 299
P105 End Deceleration Voltage 30 to 55 30 % 96
(% Un of the Motor)
P106
(1)
Automatic Detection of the 0=By Time 0=By Time - 96
Acceleration End with Voltage Ramp 1=Automatic
Current Limit
P110 CurrentLimit 150to500 300 % 96
(%In of the Motor)
P111 Initial Current for the Current Ramp 150 to 500 150 % 97
(% In of the Motor)
P112 Time for the Current Ramp 1 to 99 20 % 97
(% of P102)
Torque Control
P120
(1)
Starting Torque Characteristics 1=Constant 1=Constant - 98
  2=Linear
3=Quadratic
P121 Initial Starting Torque 10 to 400 30 % 99
(% Tn of Motor)
P122 End Starting Torque 10 to 400 110 % 99
(% Tn of Motor)
P123 Minimum Starting Torque 10 to 400 27 % 99
(% Tn of the Motor)
P124 Time for the Minimum Start Torque 1 to 99 20 % 99
(% of P102)
P125
(1)
Stopping Torque Characteristics 1=Constant 1=Constant - 100
  2=Linear
3=Quadratic
P126 End Stop Torque 10 to 100 20 % 100
(% Tn of the Motor)
P127 Minimum Stop Torque 10 to 100 50 % 101
(% Tn of the Motor)
P128 Time for the Minimum Stop Torque 1 to 99 50 % 101
(% of P104)
Pump Control
P130
(1)
Pump Control 0= Pump I 0= Pump I - 101
By-pass
P140
(1)
External By-pass Contactor 0=Inactive 0=Inactive - 101
1=Active
