PergoTex II/ PergoTex II LED
Instructions for assembly
We reserve the right to make technical changes
Installation of post plate with post to the
screw foundation
Note:
Note: The Krinner company will install the
screw foundation system.
1. Screw adaptor plate (1) to the screw
foundation with three countersunk hex
head screws M12x60 (2).
2. Tapped holes for two hex socket head
screws M12x40 (6) in the adaptor plate
(1) depending on the structural
situation.
3. Screw the post plate (3) with post (4)
with two washers 13 (5) and two hex
socket head screws M12x40 (6) to the
adaptor plate (1).
