PergoTex II/ PergoTex II LED
Instructions for assembly
We reserve the right to make technical changes
5.15 (optional) Installation of VertiTex guide rails on posts
Installing the VertiTex guide rails on
posts
3. If a VertiTex with guide rails is to be
installed on the centre/wall post please
make sure that the fixings (2) for the
VertiTex guide rails (1) are also
screwed into the U-Profiles located in
the post (3). Adjust the positions of the
U-Profiles on site, if necessary.
5.16 Installation of the protective leaf grille in the safety shield guttering
Installation of the protective leaf grille
safety shield guttering
4. Screw the protective leaf grille (1),
included in the delivery, into the safety
shield guttering (4) with 2 self tapping
screws 3.9x13 (2) and 2 washers 4.3
(3).
