PergoTex II/ PergoTex II LED
Instructions for assembly
Version 9
05.10.2017
We reserve the right to make technical changes
Item number
118697-0000
Page 21/66
5.3 Installation of the side channels
The side channels are only inserted initially. All attachment screws are only loosely
tightened as the side channels must still be aligned.
1.
Installation of the "guttering cover
plate"
1. Bolt cover plate for guttering“ (1) to the
outside side channel (3) with 1 socket
head cap screw M5x12 (2).
