PergoTex II/ PergoTex II LED
Instructions for assembly
We reserve the right to make technical changes
Installation of posts to guttering
Attach post (1) from below to the 1.
"post outside guttering connection"
(2).
Bolt the "post outside guttering 2.
connection"“ (2) to the post (1) with 4
washers 8,4 (3) and 4 socket head
cap screws M8x16 (4).
Tighten the socket head cap screws 3.
M8x16 (4) only slightly.
Putting up the posts and guttering
1. Put up the post with the mounted
guttering.
2. The socket head cap screws M8x16
(4) can now be firmly tightened.
Note:
According to the weight of the guttering,
we recommend using an assembly
trestle to lift the guttering.
If the guttering is not very wide, it can be
assembled with the post lying on its side
and then erected.
