WinGD X72-B - Hp Scr Software Info; LDU-20 Page - HP SCR SOFTWARE INFO

Item Function Effect
011 Status indication Shows the engine status
Fig 4-24 LDU-20 page - HP SCR SOFTWARE INFO
004
001 002 003
005
006
007
008
009
Tab 4-6 HP SCR SOFTWARE INFO
Item Function Effect
001 INDEX button Opens the index page
002 SCREENSHOT button Makes a screenshot of the current screen
003 RCS CTRL ON button Gets control from the remote control system (if button is active)
004 Application type Shows the name of the application
005 Software version Shows the software version number, (major) (middle) (minor),
for example 1.2.0
006 Application CRC (Cyclic Redun-
dancy Check)
Shows the check-sum of the application (binary)
007 Engine type Shows the applicable engine
008 Manufacturer number Shows the software manufacturer number
009 DB number Shows identification number of the installation
X72-B
AA00-9270-00AAA-043A-A
Operation Manual HP Selective catalytic reduction system
Winterthur Gas & Diesel Ltd.
- 113 - Issue 003 2021-12
