WinGD X72-B - MCP Buttons Function

Tab 6-2 MCP buttons function
Item Function Effect
001 START AHEAD Starts the ahead function
002 START ASTERN Starts the astern function
003 SLOW TURNING Starts the slow turning function:
•
Green light- When the slowturning is ON
•
Light off- When the slowturning is OK
•
Red Light- When the slowturning is fails
004 AUX BLOWER PRESEL Starts the aux blower presel function:
005 FUEL MODE CONTROL Starts the fuel mode control function:
•
Green light: When aux blower is in operation
006 LOCAL MANUAL CONTROL Starts the local manual control function
007 ECR MANUAL CONTROL Starts the ECR manual control function
008 SAFETY SYSTEM RESET Starts the safety system reset control function
009 SLOWTURNING FAIL/RESET Starts the slowturning fail/reset function
010 SOUNDOFF - ALMACKN Starts the sound off ALM ACKN function
011 SHD OVERRIDE Starts the SHD override function
012 BRIDGE REMOTE CONTROL Starts the bridge remote control function
012 ECR REMOTE CONTROL Starts the ECR remote control function
013 SPEED CONTROL MODE Starts the speed control mode function
014 AIR RUN Starts the air run function
014 STOP Starts the stop function
X72-B
AA00-4618-01AAB-043B-A
Operation Manual MCP page - DISPLAY
Winterthur Gas & Diesel Ltd.
- 249 - Issue 003 2021-12
