Fig 6-14 MCP page - Fuel mode control - Gas mode information
Tab 6-5 MCP page - Fuel mode control - Gas mode information
Item Function Effect
001 GAS button Switches to the gas mode, green LED turns on
002 Indication field Shows the data for gas mode (Gas interlock info)
Shows: Fuel cmd Mode Active, Speed/Load not in range, HFO
Fuel in use, Heavy Sea Mode Active, External Gas Trip PCS,
External Gas Trip iGPR, Engine Stopped, Engine Running
Astern, Internal Gas Trip
X72-B
AA00-4618-06AAA-043B-A
Operation Manual MCP page - FUEL MODE CONTROL - Option for WiCE
Winterthur Gas & Diesel Ltd.
- 252 - Issue 003 2021-12
