6.7.6 WiCE module - troubleshooting
Tab 6-27 WiCE module warning indication on the LDU-20 panel
Indication Possible trouble
Procedure
E:L2 Ethernet ring 2 left link down Re-establish the wiring of the Ethernet Ring #2. TRX-L2
to the adjacent control module.
E:R2 Ethernet ring 2 right link down Re-establish the wiring of the Ethernet Ring #2. TRX-R2
to the adjacent control module.
E:L1 Ethernet ring 1 left link down Re-establish the wiring of the Ethernet Ring #1. TRX-L1
to the adjacent control module.
E:R1 Ethernet ring 1 right link down Re-establish the wiring of the Ethernet Ring #1. TRX-R1
to the adjacent control module.
