6.5.10 MCP page - FUEL / LUBRICATION SYSTEM
This page shows status of the fuel oil and cylinder lubrication oil system.
1 Select the “Fuel MODE” (001, Figure 6-30) button from the navigation menu.
2 Select the “FUEL/LUB SYSTEM” (013) button from the sub-menu.
Fig 6-30 MCP Page - FUEL / LUBRICATION SYSTEM
001 002 003 004 005 006 007 008
009010011012013
X72-B
AA00-4618-08AAA-043B-A
