WinGD X72-B - Scavenge Air Receiver - Cross Section (Example)

Fig 5-28 Scavenge air receiver - cross section (example)
001
002
005
004
003
Legend
001 Air space 004 Outlet to piston underside
002 Longitudinal wall 005 Flap
003 Receiver space
X72-B
AA00-6420-00AAA-043A-A
Operation Manual Scavenge air receiver
Winterthur Gas & Diesel Ltd.
- 199 - Issue 003 2021-12
