Tab 6-8 MCP page - MAIN
Item Function Effect
001 Servo oil pressure Shows the servo oil pressure value in bar
002 Actual engine speed Shows the actual engine speed value in rpm
003 Fuel rail pressure Shows the fuel rail pressure value in bar
004 Indication field Shows the data for start interlocks and for limiters
Start interlock Info: Turning Gear Engaged, Main Start Air Valve
Closed, Exhaust Venting Request, Shaft Locking Device En-
gaged
Limiter Info: Torque Limiter Active, Scavenge Air Limiter Active,
Torque + Scavenge Air Limiter Active
005
Fuel mode
Shows the fuel mode
Shows: Diesel, Transfer, Gas, Gas - DCC Active, Fuel Sharing,
Diesel - Manual (Fuel control mode)
006 Gas System Shows data for the gas system
Shows: Available, Int. Gas Trip, Ext. Gas Trip, Transfer Prep.,
Operational
007 Control Shows the control mode
Shows: Bridge, ECR Remote, ECR Manual, Local
008 Engine Shows the engine status
Shows: Air Run, Slowturning, Start Interlock, Stopped, Shut-
down, Running, Starting, Heavy Start, Angle Determining, Slow-
down
009 Crank angle/ Engine load Shows the data for actual engine load in case of the engine is
in operation
Shows the data for crank angle in case of the engine is stop
010 Engine speed/ Fuel command Shows the data for engine speed in case of the engine is in op-
eration
Shows the data for fuel command in case of engine is stop
6.5.5.1 Additional information on main screen
•
Start interlock information:
○
Turning Gear Engaged
○
Main Start Air Valve Closed
○
No Aux. Blower Running
○
Exhaust Venting Request (DF)
○
Shaft locking device engaged (Twin propulsion)
•
Limiter information:
○
Same position as Start Interlock Information
