Tab 6-22 Navigation menu of the manual control panel (MCP)
Button Effect
HOME Opens the main page
INSTRUMENTS Opens the instrument page
FUEL MODE Opens a sub menu for the pages that follow:
•
Fuel mode control
•
Gas system
•
Lub. oil system
MENU Opens a sub menu for the pages that follow:
•
Info page
•
Trending page
•
Settings page
Tab 6-23 Function buttons of the manual control panel (MCP)
Button LED Effect
START AHEAD Green Starts the engine in ahead direction, green LED comes on
STOP Red Stops the engine, red LED comes on
START ASTERN Green Starts the engine in astern direction, green LED comes on
SLOW TURNING Green Starts and stops a slow turning of the engine, green LED comes
on
Slow turning stops automatically, if the crankshaft has complet-
ed one full turn, or when there was a malfunction
AIR RUN Green Starts the air run mode of the engine, green LED comes on
Operates only when the engine is stopped
AUX. BLOWER PRESEL Green Sets the auxiliary blowers to status preselect, green LED comes
on
AUX. BLOWER STOP Red Stops the auxiliary blowers manually, red LED comes on
FUEL CONTROL MODE Green Sets the fuel control mode, green LED comes on, green LED of
SPEED CONTROL MODE goes off
Use the fuel dial knob to adjust the value.
NOTE: The ECS automatically changes to fuel control mode,
if the speed control system becomes defective, or if
fuel injection quantity adjustment is necessary.
SPEED CONTROL MODE Green Sets the speed control mode, green LED comes on, green LED
of FUEL CONTROL MODE goes off
Use the fuel dial knob to adjust the value.
