Software image download Configuration image download Normal Boot up without download
U:PU: pull update check initiat-
ed
U:PU: pull update check initiated U:PU: pull update check initiated
U:SI: push single update initiat-
ed
U:SI: push single update initiated SM:I: USM state “Initialization”
U:SW: software update initiated U:CF: config update initiated SM:R: USM state “Ready”
Reboot
Reboot Blank
Fig 6-40 WiCE - Cylinder Control Unit (CCU) module replacement
005
006
004
003
001
002
X72-B
AA00-0000-00AAA-200C-A
Operation Manual WiCE - Cylinder Control Unit (CCU) module replacement
Winterthur Gas & Diesel Ltd.
- 295 - Issue 003 2021-12
