WinGD X72DF User Manual

3 Lower the crankshaft.
3.1 On the HP oil pump, release the pressure to fully lower the crankshaft.
3.2 Remove the hydraulic rams (001, Figure 6-15) and the HP oil pump.
3.3 Remove the bracket (003) and the steel plate (002).
Fig 6-15 Crankshaft and flywheel - lift
001
003
001
005
002
004
CLOSE UP
• None
X72DF
AA00-1134-00AAA-720A-A
Maintenance Manual Main bearing shell - install
Winterthur Gas & Diesel Ltd.
- 130 - Issue 002 2020-10
