Manual 37278B GCP-30 Series - Genset Control
© Woodward Page 147/174
No. Output Explanation
114
#1
Three-position controller: n+ / f+ / P+
(use an external RC protection cir-
cuit)
115
#1
Three-position controller: n- / f- / P-
116
#1
Three-position controller: V+ / Q+
117
#1
Three-position controller: V- / Q-
118
#2
Mains monitoring df/dt
119
#3
Wire break Analog input [T1]
120
#3
Wire break Analog input [T2]
121
#3
Wire break Analog input [T3]
122
#3
Wire break Analog input [T4]
123
#3
Wire break Analog input [T5]
124
#3
Wire break Analog input [T6]
125
#3
Wire break Analog input [T7]
126
#4
Relay for gas supply test
127
#5
Temperature too low and generator voltage/frequency within range
128
#6
--Internal--
Direct configuration via LeoPC1
starting with Version 3.0.015
possible.
129
#7
Failure lambda probe
130
#7
Lambda controller ON
131 Fuel relay is ON / stop relay is ON / gas valve is ON
132
#5
Temperature dependent enabling of a fan
133 Idle mode active
134
#7
IKD1 communication OK
135
#7
IKD2 communication OK
136
#7
ST3 communication OK
137
#7
MDEC communication OK
138
#7
J1939 communication OK
139 Phase rotation generator/busbar or busbar/mains mismatch
140 Direction of rotation, mains voltage: CW
141 Direction of rotation, generator voltage: CCW
142 Direction of rotation, generator voltage: CW
143 Starter engaged (cranking)
144 GCB is to be opened
145
#6
--Internal--
146 Parallel operation CB from V4.3010
147
#8
Timer switch
148 Unintended stop from V4.3010
149 Interface error X1/X5 from V4.3010
150
#9
ECU yellow alarm from V4.3030
151
#9
ECU red alarm from V4.3030
152
#10
Mains connected detected by angle
153
#10
Mains power measurement active
#1
(Package Q, Option Q),
#2
(Option DFDT),
#3
(Package XP, Option T701),
#4
(Option D02),
#5
(Option TZ02),
#6
special versions only,
#7
(Option SC06),
#8
(Package RPQ, Option Z01),
#9
(Option SCxx),
#10
(Package RPQ)
