GENERAL
L3301, L3901, L4701, WSM
G-109
10. IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by
KUBOTA. Use with implements which exceed the maximum specifications listed below, or which are otherwise unfit
for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor, damage to other property and
injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use with improper implements
are not covered by the warranty.]
• Implement size may vary depending on soil operating conditions.
9Y1211012GEG0051US0
Tread (max. width)
Lower link end max.
loading weight W0
Front Rear
L3301
L3901
1050 mm
(41.3 in.)
1095 mm
(43.1 in.)
1290 mm (50.8 in.) 900 kg (1985 lbs)
L4701
1580 mm
(62.2 in.)
1155 mm
(45.5 in.)
1545 mm (60.8 in.) 1300 kg (2870 lbs)
Actual figures
Implement weight W1 and /
or size
Max. Drawbar Load W2
Trailer loading weight W3
Max. capacity
L3301
L3901
As in the following list
(Shown on the next pate)
330 kg (730 lbs) 1000 kg (2200 lbs)
L4701 650 kg (1430 lbs) 3000 kg (6600 lbs)
Lower link end max. hydraulic lift capacity: W0
Implement weight: The implement weight which you can put on the link: W1
Max. drawbar load: W2
Trailer loading weight: The max loading weight for trailer (without trailer weight): W3
