wsm L3301 - Servicing Specifications

BRAKES
L3301, L3901, L4701, WSM
5-S2
2. SERVICING SPECIFICATIONS
9Y1211012BRS0002US0
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 15 to 20 mm
0.6 to 0.8 in.
–
Cam Plate Flatness – 0.3 mm
0.01 in.
Cam Plate and Ball Height 20.9 to 21.1 mm
0.823 to 0.830 in.
20.5 mm
0.807 in.
Brake Disc Thickness 4.60 to 4.80 mm
0.182 to 0.188 in.
4.2 mm
0.17 in.
Plate Thickness 2.54 to 2.66 mm
0.100 to 0.104 in.
2.1 mm
0.083 in.
KiSC issued 09, 2016 A
