BRAKES
L3301, L3901, L4701, WSM
5-S1
1. TROUBLESHOOTING
9Y1211012BRS0001US0
Symptom Probable Cause Solution
Reference
Page
Uneven Braking
Force
Brake pedal play unevenly adjusted Adjust 5-S4
Brake disc worn Replace 5-S11,
5-S12
Cam plate warped Replace 5-S11,
5-S12
Brake Drags Too little free play in the brake pedals Adjust 5-S4
Ball holes of cam plate for uneven wear Replace 5-S11,
5-S12
Brake pedal return spring weaken or broken Replace –
Brake cam rusted Repair –
Poor Braking Force Too much free play in the brake pedals Adjust 5-S4
Brake disc worn Replace 5-S11,
5-S12
Cam plate warped Replace 5-S11,
5-S12
Brake cam or lever damaged Replace 5-S11
KiSC issued 09, 2016 A
