STEERING
L3301, L3901, L4701, WSM
7-S3
2. SERVICING SPECIFICATIONS
STEERING WHEEL PLAY
POWER STEERING
RELIEF VALVE
Item Factory Specification Allowable Limit
Steering Wheel [L3301/L3901] Play 20 to 50 mm
0.79 to 1.9 in.
–
Item Factory Specification Allowable Limit
Hydraulic Pump [L3301/L3901]
Condition
• Engine Speed:
approx. 2700 min
-1
(rpm)
• Oil Temperature:
40 to 60 °C (104 to 140 °F)
Delivery at
No Pressure
Delivery at
Rated Pressure
Above
14.4 L/min.
3.80 U.S.gals/min.
3.17 Imp.gals/min.
Above
14.1 L/min.
3.72 U.S.gals/min.
3.10 U.S.gals/min.
–
11.9 L/min.
3.14 U.S.gals/min.
2.62 Imp.gals/min.
Hydraulic Pump [L4701]
Condition
• Engine Speed:
approx. 2600 min
-1
(rpm)
• Oil Temperature:
40 to 60 °C (104 to 140 °F)
Delivery at
No Pressure
Delivery at
Rated Pressure7
Above
17.7 L/min.
4.68 U.S.gals/min.
3.89 Imp.gals/min.
Above
17.4 L/min.
4.60 U.S.gals/min.
3.83 Imp.gals/min.
–
14.6 L/min.
3.86 U.S.gals/min.
3.21 Imp.gals/min.
Item Factory Specification Allowable Limit
Relief Valve [L3301]
Condition
• Engine Speed:
Maximum
• Oil Temperature:
40 to 60 °C (104 to 140 °F)
Steering Pressure
[2WD]
Steering Pressure
[4WD]
8.3 to 9.3 MPa
85 to 95 kgf/cm
2
1200 to 1300 psi
11.4 to 12.4 MPa
116 to 126 kgf/cm
2
1650 to 1790 psi
–
–
Relief Valve [L3901]
Condition
• Engine Speed:
Maximum
• Oil Temperature:
40 to 60 °C (104 to 140 °F)
Steering Pressure
[2WD]
Steering Pressure
[4WD]
8.1 to 9.1 MPa
83 to 93 kgf/cm
2
1200 to 1300 psi
11.1 to 12.1 MPa
113 to 123 kgf/cm
2
1610 to 1740 psi
–
–
Relief Valve [L4701]
Condition
• Engine Speed:
Maximum
• Oil Temperature:
40 to 60 °C (104 to 140 °F)
Steering Pressure
[2WD]
Steering Pressure
[4WD]
8.0 to 9.0 MPa
81 to 91 kgf/cm
2
1200 to 1300 psi
10.7 to 11.7 MPa
109 to 119 kgf/cm
2
1550 to 1690 psi
–
–
KiSC issued 09, 2016 A
