INFORMATION
L3301, L3901, L4701, WSM
I-10
3. SPECIFICATIONS
[1] L3301/L3901
Model
L3301 L3901
Manual Transmission HST Manual Transmission HST
2WD 4WD 4WD 2WD 4WD 4WD
PTO power* 20.7 kW (27.7 HP)
19.5 kW
(26.2 HP)
23.9 kW (32.1 HP)
22.8 kW
(30.6 HP)
Engine
Model D1803-CR-E4
Type Direct injection, vertical, water-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke 87 × 102.4 mm (3.4 × 4.0 in.)
Total displacement 1.826 L (111.4 cu.in.)
Engine gross power* 24.6 kW (33.0 HP) 28.0 kW (37.5 HP)
Engine net power* 23.4 kW (31.4 HP) 27.1 kW (36.3 HP)
Rated revolution 45.0 rps (2700 rpm)
Low idling revolution 15.0 rps (900 rpm)
Maximum torque 101.7 N·m (75.0 lbf·ft) 115.8 N·m (85.4 lbf·ft)
Battery [75D23R] 12 V, RC: 110 min, CCA: 580 A
Capacities
Fuel tank 42.0 L (11.0 U.S.gals, 9.24 Imp.gals)
Engine crankcase (with filter) 6.7 L (7.1 U.S.qts, 5.9 Imp.qts)
Engine coolant 6.0 L (6.3 U.S.qts, 5.3Imp.qts)
Transmission case
28.0 L
(7.4 U.S.gals,
6.16 Imp.gals)
28.5 L
(7.5 U.S.gals,
6.27 Imp.gals)
23.5 L
(6.2 U.S.gals,
5.17 Imp.gals)
28.0 L
(7.4 U.S.gals,
6.16 Imp.gals)
28.5 L
(7.5 U.S.gals,
6.27 Imp.gals)
23.5 L
(6.2 U.S.gals,
5.17 Imp.gals)
Dimensions
Overall length (without 3p)
2810 mm
(110.6 in.)
2740 mm (107.9 in.)
2810 mm
(110.6 in.)
2740 mm (107.9 in.)
Overall width (min. tread) 1400 mm (55.1 in.)
Overall height (with ROPS) 2330 mm (91.7 in.)
Overall height
(Top of steering wheel)
1475 mm (58.1 in.)
Wheel base 1610 mm (63.3 in.)
Min. ground clearance
345 mm
(13.6 in.)
340 mm (13.4 in.)
345 mm
(13.6 in.)
340 mm (13.4 in.)
Tread
Front
1050 mm
(41.3 in.)
1095 mm (43.1 in.)
1050 mm
(41.3 in.)
1095 mm (43.1 in.)
Rear 1115 mm (43.8 in.), 1195 mm (47.1 in.), 1290 mm (50.8 in.)
Weight (with ROPS)
1160 kg
(2557 lbs)
1240 kg
(2734 lbs)
1260 kg
(2778 lbs)
1175 kg
(2590 lbs)
1255 kg
(2767 lbs)
1260 kg
(2778 lbs)
Traveling
system
Tire
AG Front 5.00-15 7.2-16 5.00-15 7.2-16
AG Rear 11.2-24
Industrial
(option)
Front – 27 × 8.50-15 – 27 × 8.50-15
Rear – 15-19.5R4 – 15-19.5R4
Clutch Dry type single stage Dry type dual stage
Dry type
single stage
Steering Integral type power steering
Transmission
Gear shift, 8 forward and
8 reverse
Hydrostatic
transmission,
3 range
speed
Gear shift, 8 forward and
8 reverse
Hydrostatic
transmission,
3 range
spee
d
Brake Wet disk type
Min. turning r
adius
(with brake)
2.4 m
(7.9 feet)
2.5 m (8.2 feet)
2.4 m
(7.9 feet)
2.5 m (8.2 feet)
Hydraulic unit
Hydraulic control system Position control
Pump capacity (main) 23.9 L/min (6.3 gals/min., 5.26 Imp.gals/min.)
Pump capacity (PS) 14.5 L/min (3.8 gals/min, 3.19 Imp.gals/min.)
Three point hitch Category 1
Max. lift force
At lift points 906 kg (1998 lbs)
24 in. behind
lift points
651 kg (1435 lbs)
System pressure 16.2 MPa (165 kgf/cm
2
, 2349 psi)
