4. LUBRICANTS, FUEL AND COOLANT
[1] L3301/L3901
NOTE
• KUBOTA UDT or SUPER UDT fluid: KUBOTA original transmission hydraulic fluid.
9Y1211012GEG0005US0
No. Place
Capacity
Lubricants, fuel and coolant
L3301 L3901
1Fuel
42.0 L
11.0 U.S.gals
9.24 Imp.gals
• No. 2-D S15 diesel fuel
• No. 1-D S15 diesel fuel if temperature is
below –10 °C (14 °F)
2Coolant
6.0 L
6.3 U.S.qts
5.3 Imp.qts
Fresh clean soft water with anti-freeze
3 Engine crankcase (with filter)
6.7 L
7.1 U.S.qts
5.9 Imp.qts
Engine oil: Refer to G-12.
• Above 25 °C (77 °F)
SAE30, SAE10W-30 or 15W-40
• −10 to 25 °C
(14 to 77 °F)
SAE20, SAE10W-30 or 15W-40
• Below −10 °C (14 °F)
SAE10W-30
4
Transmission
case
Manual
Transmission,
2WD
28.0 L
7.4 U.S.gals
6.16 Imp.gals
KUBOTA SUPER UDT-2 fluid
Manual
Transmission,
4WD
28.5 L
7.5 U.S.gals
6.27 Imp.gals
HST, 4WD
23.5 L
6.2 U.S.gals
5.17 Imp.gals
5 Front axle case [4WD]
4.5 L
4.8 U.S.qts
4.0 Imp.qts
KUBOTA SUPER UDT-2 fluid or SAE80,
90 gear oil
Greasing
Place No. of greasing point Capacity Type of grease
6
Front wheel hub 2 [2WD only] A small amount Bearing grease
Knuckle shaft 2 [2WD only]
Until grease
overflows
Multipurpose type
grease
NLGI-2 or NLGI-1
(GC-LB)
Front axle support 2 [4WD only]
Clutch pedal 1
Brake pedal 1
Pedal shaft 1
Battery terminals 2
Lift rod 2
Tie rod end 4 [4WD only]
Top link 2
