wsm L3301 - 2 Servicing Specifications

ELECTRICAL SYSTEM
L3301, L3901, L4701, WSM
9-S8
2. SERVICING SPECIFICATIONS
9Y1211012ELS0002US0
Item Factory Specification Allowable Limit
Glow Plug Resistance Approx.
0.9 Ω
–
Fuel Level Sensor
• Float at Upper-most Position
• Float at Middle Position
• Float at Lower-most Position
Resistance
Resistance
Resistance
1.0 to 5.0 Ω
32.5 Ω
103 to 117 Ω
–
–
–
Coolant Temperature Sensor
•at −20 °C (−4 °F)
• at 0 °C (32 °F)
• at 20 °C (68 °F)
• at 40 °C (104 °F)
• at 60 °C (140 °F)
• at 80 °C (176 °F)
• at 100 °C (212 °F)
• at 120 °C (248 °F)
Resistance
Resistance
Resistance
Resistance
Resistance
Resistance
Resistance
Resistance
15.04 kΩ
5.74 kΩ
2.45 kΩ
1.15 kΩ
0.58 kΩ
0.32 kΩ
0.18 kΩ
0.11 kΩ
–
–
–
–
–
–
–
–
Starter
• Commutator
•Mica
•Brush
• Brush Holder and Holder Support
O.D.
Under Cut
Length
Resistance
30.0 mm
1.181 in.
0.50 to 0.80 mm
0.020 to 0.031 in.
15.0 mm
0.591 in.
Infinity
29.0 mm
1.142 in.
0.20 mm
0.0008 in.
11.0 mm
0.433 in.
–
Alternator
• Stator
• Rotor
• Slip Ring
•Brush
No-load voltage
Resistance
Resistance
O.D.
Length
More than
14 V
Less than
1.0 Ω
2.9 Ω
14.4 mm
0.567 in.
10.5 mm
0.413 in.
–
–
–
12.8 mm
0.504 in.
14.0 mm
0.551 in.
8.4 mm
0.331 in.
KiSC issued 09, 2016 A
