ELECTRICAL SYSTEM
L3301, L3901, L4701, WSM
9-S9
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1211012ELS0003US0
Item N·m kgf·m lbf·ft
Steering wheel nut 48.0 to 55.9 4.9 to 5.7 36 to 41
Rear bonnet mounting bolt 4 to 5 0.4 to 0.6 3 to 4
Starter terminal nut 5.9 to 11 0.60 to 1.2 4.4 to 8.6
Alternator pulley nut 58.4 to 78.9 5.95 to 8.05 43.1 to 58.2
To Next Page
