wsm L3301 - L4701

INFORMATION
L3301, L3901, L4701, WSM
I-12
[2] L4701
NOTE
• *Manufacturer's estimate. The company reserve the right to change the specifications without notice.
9Y1211012INI0009US0
Model
L4701
Manual Transmission HST
2WD 4WD
Engine
Model V2403-CR-E4
Type Direct injection, vertical, water-cooled, 4-cycle diesel
Number of cylinders 4
Total displacement 2.434 L (148.5 cu.in.)
Bore and stroke 87 × 102.4 mm (3.4 × 4.0 in.)
Rated revolution 2600 min
-1
(rpm)
Low idling revolution 800 min
-1
(rpm)
Net power* 33.4 kW (44.8 HP) / 2600 min
-1
(rpm)
PTO power*
(factory observed)
29.3 kW (39.3 HP) / 2600 min
-1
(rpm) 28.2 kW (37.8 HP) / 2600 min
-1
(rpm)
Maximum torque: Gross 146.2 N·m (107.8 lbf·ft)
Battery capacity 12 V, RC: 120 min, CCA: 600 A
Capacities
Fuel tank 51 L (13.5 U.S.gals, 11 Imp.gals)
Engine crankcase (with filter) 8.2 L (8.7 U.S.qts, 7.2 Imp.qts)
Engine coolant 6.5 L (6.9 U.S.qts, 5.7 Imp.qts)
Transmission case 40 L (10.6 U.S.gals, 8.8 Imp.gals)
Dimensions
Overall length (without 3p) 3120 mm (122.8 in.) 3035 mm (119.5 in.)
Overall width (min. tread) 1585 mm (62.4 in.)
Overall height (with ROPS) 2330 mm (91.7 in.)
Wheel base 1850 mm (72.8 in.) 1845 mm (72.6 in.)
Min. ground clearance 385 mm (15.2 in.)
Tread
Front
1280 mm (50.4 in.),
1380 mm (54.3 in.),
1480 mm (58.3 in.),
1580 mm (62.2 in.)
1155 mm (45.5 in.)
Rear
1180 mm (46.5 in.), 1200 mm (47.2 in.), 1300 mm (51.2 in.),
1450 mm (57.1 in.),1545 mm (60.8 in.)
Weight (with ROPS)
1460 kg
(3219 lbs)
1495 kg
(3296 lbs)
1500 kg (3307 lbs)
Traveling
system
Standard tire
size
Front 7.5L-15 8.3-16
Rear 14.9-24
Clutch Dry type single stage –
Steering Hydrostatic power steering
Transmission Gear shift, 8 forward and 8 reverse Hydrostatic transmission 3 range speed
Braking system Mechanical, Wet disk type
Min. turning radius
(with brake)
2.7 m (8.9 feet) 2.6 m (8.5 feet)
Hydraulic unit
Hydraulic control system Position control
Pump capacity 29.4 L (7.8 U.S.gals, 6.47 Imp.gals) /min.
Three point hitch Category 1
Max. lift force
At lift points 1300 kg (2870 lbs)
24 in. behind
lift points
1053 kg (2320 lbs)
System pressure 17.7 MPa (180 kgf/cm
2
, 2560 psi)
PTO
Rear PTO
PTO shaft
size
SAE 1-3/8, 6 splines
PTO / Engine speed 540 min
-1
(rpm) / 2475 min
-1
(rpm) 540 min
-1
(rpm) / 2640 min
-1
(rpm)
KiSC issued 09, 2016 A
