STEERING
L3301, L3901, L4701, WSM
7-S4
HYDRAULIC PUMP
STEERING GEAR BOX
9Y1211012STS0003US0
Item Factory Specification Allowable Limit
Housing Bore Depth of scratch 0.09 mm
0.0035 in.
–
Bushing to Gear Shaft
• Gear shaft
• Bushing
Clearance
O.D.
I.D.
0.020 to 0.081 mm
0.0008 to 0.0032 in.
14.970 to 14.980 mm
0.5894 to 0.5898 in.
15.000 to 15.051 mm
0.5906 to 0.5926 in.
0.15 mm
0.0059 in.
–
–
Side Plate Thickness 2.48 to 2.50 mm
0.0976 to 0.0984 in.
2.40 mm
0.0945 in.
Item Factory Specification Allowable Limit
Sector Gear to Ball Nut Clearance 0.3 mm
0.01 in.
–
Valve Housing to Spool Clearance 0.17 to 0.28 mm
0.0067 to 0.011 in.
0.04 mm
0.02 in.
Steering Gear Box and Ball Nut Clearance 0.035 to 0.080 mm
0.0014 to 0.0031 in.
0.15 mm
0.0059 in.
Ball Nut Assembly Axial Play 0.02 mm
0.0008 in.
0.04 mm
0.001 in.
