ENGINE
L3301, L3901, L4701, WSM
1-M22
Auto Mode
: Lighting, : Flashing
9Y1211012ENM0039US0
Regeneration INHIBIT Mode
: Lighting, : Flashing
9Y1211012ENM0040US0
Auto Mode
REGENER-
ATION INDI-
CATOR
PARKED
REGENER-
ATION INDI-
CATOR
WARNING
INDICATOR
Buzzer
Interval
State
Level 0
(No need
Regeneration)
Not
sounding
Regeneration is not required
Level 1
(Auto Regeneration)

Not
sounding
The regeneration cycle begins and continues until
cycle is complete then the indicator will turn "OFF".
Level 2
(Request parked
Regeneration)

every few
seconds
The parked regeneration indicator start flashing, and
the parked regeneration can also be started.
Level 3
(Parked
Regeneration)

every
1 second
At this PM warning level, the Auto Regeneration
Mode does not function. If the tractor is operated
further, the regeneration cycle will be disabled.
Output of tractor is restricted.
Level 4
(Regeneration with
service tools)

every
1 second
Parked regeneration is impossible.
Regeneration is possible with service tools only.
(Service tools are available among all levels without
level 5)
Level 5
(DPF Cleaning)

every
1 second
Regeneration is impossible even with service tools.
DPF cleaning is necessary.
INHIBIT Mode
REGENER-
ATION INDI-
CATOR
PARKED
REGENER-
ATION INDI-
CATOR
WARNING
INDICATOR
Buzzer
Interval
State
Level 0
(No need
Regeneration)
Not
sounding
Regeneration is not required
Level 1
(Auto Regeneration)

Not
sounding
A specific level of PM has built up in the DPF muffler.
Level 2
(Request parked
Regeneration)

every few
seconds
Move the tractor to a safe area, then do the Parked
Regeneration.
Level 3
(Parked
Regeneration)

every
1 second
Immediately stop working the tractor, move the
tractor to a safe area, then do the Parked
Regeneration.
If the tractor is operated further and the operator
ignores the warning signs, then regeneration will be
disabled.
Level 4
(Regeneration with
service tools)

every
1 second
Parked regeneration is impossible.
Regeneration is possible with service tools only.
(Service tools are available among all levels without
level 5)
Level 5
(DPF Cleaning)

every
1 second
Regeneration is impossible even with service tools.
DPF cleaning is necessary.
