REAR AXLE
L3301, L3901, L4701, WSM
4-S2
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1211012RAS0002US0
Item N·m kgf·m lbf·ft
Rear wheel mounting screw and nut 197 to 225 20.0 to 23.0 145 to 166
ROPS lower frame mounting screw 167 to 196 17.0 to 20.0 123 to 144
ROPS fulcrum bolt and nut 118 to 137 12.0 to 14.0 86.8 to 101
Rear axle case mounting M10 bolts 48.0 to 55.9 4.9 to 5.7 36 to 41
Rear axle case mounting M10 nuts (L3301/L3901) 48.1 to 55.9 4.9 to 5.7 36 to 41
Rear axle case mounting M10 nuts (L4701) 60.8 to 70.6 6.2 to 7.2 45 to 52
Rear axle case mounting M12 bolts and nuts
(L4701 only)
77.5 to 90.2 7.9 to 9.2 58 to 66
Lock nut 200 to 240 20 to 25 150 to 180
