FRONT AXLE
L3301, L3901, L4701, WSM
6-S3
[4WD]
Item Factory Specification Allowable Limit
Toe-in 2 to 8 mm
0.08 to 0.3 in.
–
Front Wheel Axial Sway Less than
5.0 mm
0.20 in.
–
Front Axle Rocking Force 49 to 196 N·m
5.0 to 20.0 kgf·m
11 to 44 lbf·ft
–
Bevel Gear Case to Stopper Clearance 2.0 mm
0.079 in.
–
Spiral Bevel Pinion Shaft Turning Torque 0.98 to 1.1 N·m
0.10 to 0.12 kgf·m
0.73 to 0.86 lbf·ft
–
Differential Case, Differential Case Cover to
Differential Side Gear
• Differential Case
• Differential Case Cover
• Differential Side Gear
Clearance
I.D.
I.D.
O.D.
0.0500 to 0.151 mm
0.00197 to 0.00594 in.
32.000 to 32.062 mm
1.25984 to 1.26228 in.
32.000 to 32.025 mm
1.25984 to 1.26083 in.
31.911 to 31.950 mm
1.25634 to 1.25787 in.
0.20 mm
0.079 in.
–
–
–
Pinion Shaft to Differential Pinion
• Pinion Shaft
• Differential Pinion
Clearance
O.D.
I.D.
0.064 to 0.100 mm
0.00252 to 0.00394 in.
13.950 to 13.968 mm
0.54922 to 0.54992 in.
14.032 to 14.050 mm
0.55244 to 0.55315 in.
0.25 mm
0.0096 in.
–
–
Differential Pinion to Differential Side Gear Backlash 0.1 to 0.3 mm
0.004 to 0.01 in.
0.4 mm
0.016 in.
Spiral Bevel Pinion Shaft to Spiral Bevel
Gear
Backlash 0.1 to 0.3 mm
0.004 to 0.012 in.
–
11T Bevel Gear to 16T Bevel Gear Backlash 0.15 to 0.35 mm
0.006 to 0.012 in.
0.6 mm
0.024 in.
11T Bevel Gear to 42T Bevel Gear. Backlash 0.15 to 0.35 mm
0.006 to 0.012 in.
0.6 mm
0.024 in.
Front Axle Case Boss (Front) to Bracket
Bushing (Front)
• Front Axle Case Boss (Front)
• Bushing
Clearance
O.D.
I.D.
0.120 to 0.275 mm
0.00472 to 0.01083 in.
49.950 to 49.975 mm
1.96653 to 1.96752 in.
50.095 to 50.225 mm
1.97224 to 1.97736 in.
0.50 mm
0.01969 in.
–
–
