Xerox 700 Digital Color Press - Inverter (Bottom Right Cover)

8-11User Guide
Problem SolvingXerox 700 Digital Color Press
This section describes how to clear paper jams that occur in the Bottom Right Cover.
Inverter (Bottom Ri
g
ht Cover
)
1. If a finisher is installed, open the front door of the
finisher and then open the Bottom Right Cover by
pressing the down arrow button.
2. If the Output Catch Tray is installed, open the Bottom
Right Cover while pressing the down arrow button.
3. Pull sheet straight down towards floor.
WARNING
When clearing this jam, the sheet should be pulled straight down towards the floor. Pulling the sheet at an angle
towards the front of the machine can cause damage to the Fuser roll.
