Product Overview
User Guide
1-2
Xerox 700 Digital Color Press
1
2
3
5
4
5.
3.
2.
4.
The Control Panel is divided into four areas: Touch Screen,
Pathway buttons, Keypad and Feature buttons.
Touch Screen
The touch screen allows you to select all the available
programing features. It also displays fault clearance
procedures and general machine information.
Services
Allows access to the Services screen, where different features (copy, scan, etc.) can be viewed and programmed.
Access to the All Services button is also available from the services screen. This button is located in the top right
of the touch screen.
Job Status
Displays job progress information on the touch screen.
Log In/Out
Provides password protected access to the System Administration menu used to adjust the defaults of the
machine.
Machine Status
Displays the current status of the machine on the touch screen.
Control Panel
1.
