User Guide3-4
Paper
Xerox 700 Di
g
ital Color Press
The Bypass Tray is a paper tray on the left hand side of your
machine. It can be folded away when not in use. It is primarily
intended for use as a small quantity, special materials feeder and
accommodates stock of all types. Stock can be loaded either
long or short edge feed (portrait or landscape).
The Bypass Tray accommodates all types of stock in a range of sizes between 4.0 x 6.0 in./101.6 x 152.4 mm and 13 x
19.2 in./SRA3/330 x 488 mm, and has a capacity of approximately 250 sheets of 20 lb./75 gsm paper or a maximum
stack height of 0.4 in./10.16 mm.
Hole punched paper should be loaded with the holes on the leading (right) edge.
Tabbed stock should be loaded with the tabs on the trailing (left) edge.
The Bypass Tray is only 13 in./330.2 mm wide, so some paper
sizes must be Short Edge Feed (SEF).
Note
When lowered, the Bypass Tray can be extended to support longer length stock.
Bypass Tray (Tray 5)
