Replacing Consumables
415
Maintenance
14
5
Prepare a new staple case. Insert
the front of the staple case into the
staple cartridge (1), and push the
rear of the case to set (2).
6
Hold the orange lever to push the
staple cartridge into the machine
until you hear it click into place.
7
Close the front cover of the finisher.
Note • If you do not completely close the front cover, the machine will display a message and not
resume operation.
Replacing the Staple Cartridge for Booklet (When a C-Finisher with
Booklet Maker is Installed)
When the C-Finisher with Booklet Maker (optional) is installed and it is time to replace
the booklet staple cartridge, a message appears on the display. When the message
appears, load a new staple case into the staple cartridge.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only staple cartridges recommended by Fuji Xerox.
Note • To order a new staple cartridge, contact our Customer Support Center.
1
Make sure that the machine has
stopped, and open the front cover
of the finisher.
2
While pressing the levers R2 and
R3 to the right, pull out the unit.
1
2
Orange lever
To Next Page
